Name: 2D Wireless Inverted Data Matrix Tobacco Scan Barcode Scanner
Brand: Guangzhou Winson Information Technology Co., Ltd.
Availability: InStock

Home Products Wireless

2D Wireless Inverted Data Matrix Tobacco Scan Barcode Scanner

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Winson

Contact Now

Detailed Product Description

Private Mold:	Yes	Products Status:	Stock
Type:	Barcode Scanner	Scan Element Type:	CMOS
Colour Depth:	32 Bit	Interface Type:	Usb, SCSI, IEEE 1394, COM, PS/2
Max Paper Size:	N/a	Optical Resolution:	648*480 Pix
Scan Speed:	5mil	Warranty(year):	1-Year
After-sales Service:	Call Center And On-line Technical Support	Software Development Kit (sdk):	Yes
Color:	Black	Communication Frequency:	433MHz - 440MHz ISM Band
Transmission Range:	100m(In Empty Area )	Battery Capacity:	2000mAh (Lithium Battery)
Charge Time From Empty To Full Charge:	4H	Continuous Working Hours:	11H
Memory:	100000 13 Digit Data Barcodes	Interface Supported:	USB HID KEYBOARD/USB VCP
Input Voltage:	DC 5V±5%	Current:	Max:180mA

Product Description

Specification

Communication mode	Wired transmission mode/ Wireless Read-time mode/Inventory mode／Cache mode
Communication frequency	433MHz - 440MHz ISM band
Transmission range	100m（In empty area ）
Battery capacity	2000mAh (Lithium battery)
Charge Time from Empty to Full Charge	4H
Continuous working hours	11H
Memory	100000 13 digit data barcodes
Interface Supported	USB HID KEYBOARD/USB VCP
Input Voltage	DC 5V±5%
Current	Max:180mA
Image Sensor	CMOS Array Sensor
Sensor Resolution	640 X 480 Pixels
Light Source	white LED
Aiming light source	RED LED
Decoding speed	60FPS
Scanning Angle	Pitch angle:±60°;Skew angle:±60°;Tilt angle:±360°
Field of View	40H),29V)
Min Resolution	4mil
Min .PCS value	≥30% UPC/EAN 13（13mil）
Language	Multiple Languages
Data Edition	Support for custom data output
Decode Capability	1D：UPC-A , UPC-E, EAN-8, EAN-13,EAN-14, EAN-128,GS1-128, UCC128, ISBN/ISSN,CODE 11, CODE 32, CODE 39, CODE 39 Full ASCII, CODE93, CODE 128,UK/Plessey, Interleaved 2 of 5,Pharmacode,Codabar 2D ：QR code, PDF417,Data matrix,Maxi code,Aztec
Dimensions	scanner :95mm67mm170mm(LWH) Lampstand:143mm x108mm x 70mm(LWH)
Weight	scanner :160g Lampstand:160g
Indicator	Beeper, LED
Temperature	-20°∽50°C (operation) -40°∽70°C (storage)
Humidity	Relative humidity: 5% to 95% (no condensation)
