Name: 2D Wireless High Speed Barcode Scanner with LED Light USB Bluetooth and COMS Interface for Industrial Scanning in Stock
Brand: Guangzhou Winson Information Technology Co., Ltd.
Availability: InStock

Home Products Industrial Barcode Scanner

2D Wireless High Speed Barcode Scanner with LED Light USB Bluetooth and COMS Interface for Industrial Scanning in Stock

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	winson

Contact Now

Detailed Product Description

Private Mold:	Yes	Products Status:	Stock
Type:	Barcode Scanner	Scan Element Type:	CMOS
Colour Depth:	32 Bit	Interface Type:	Usb, COM, PS/2
Max Paper Size:	N/a	Optical Resolution:	1920*1080
Scan Speed:	350 Scans/second	Warranty(year):	1-Year
After-sales Service:	Call Center And On-line Technical Support	Software Development Kit (sdk):	NO
Color:	Black	Size:	92mmX75mmX184mm
Weight:	Weight	Voltage Requirement:	DC 5V±5%
Interface:	USB HID Keyboard/USB VCP/RS232	Lighting Source:	Illumination:5600k White LED
View Field:	DP:H:54°,H33°	Operating Temperature:	-20°C To 50°C/-4°F To 122°F
Storage Temperature:	-40°C To 70°C/-40°F To 158°F

Product Description

Specification

Size	92mm×75mm × 184 mm(LWH)
Weight	240g
Input Voltage	DC 5V ±5%
Working Current	280mA
Stand-by Current	60mA
Color	Orange+ black
Interface	USB HID Keyboard/USB VCP/RS232
Indicator	LED Indicator/Buzzer/Vibration
Light Source	White LED
Aim Light Source	Red bar LED
Field of View	Horizon: 54°, Vertical: 33°
Sensor Resolution	1280 × 800 pixels
Min Print Contras	Min reflection difference 15%
Scan Angle	TiltAngle: ±65° Skew Angle: ±60° Rotate Angle : ±180°
Reading Accuracy	1D: ≧4mil 2D: ≧:7mil
Environmental parameters	RoHS: IEC62321-3-l:2013 Ed.1.0, IEC 62321-5:2013 Ed.1.0, IEC 62321-4:2013+AMD1:2017,IEC62321-7-l:2015 Ed.1.0, IEC 62321-7-2:2017 Ed.1.0, IEC 62321-6:2015 Ed.1.0 IEC 62321-8:2017 Ed.1.0
Electrical Safety	EU Security Law: EN 62368-1: 2014 + EN 62479: 2010 + ETSI EN 301489-1 V2.l.l (2017-02) + ETSI EN 301489-17 V3.l.l (2017-02) +ETSI EN 300 328 V2.l.l (2016-11) U.S. Security Law: FCC PartlS Subpart C 2018, Section 15.247
1D	UPC-A/UPC-E,EAN-8/EAN-13,Code128,Cod e39,Code93, Code32,Codell,Codabar,Plessey,MSI,Interleaved 2 of 5, IATA 2 of 5,Matrix 2 of 5,Straight 2 of 5,Pharmacode,RSS- 14,RSS-14 Ex panded,RSS-14 Limi ted,Compos i te Code-A, Composite Code-B,Composite Code-C
2D	PDF417,Micro PDF417,Data Matrix,QR code,Micro QR, Aztec,MaxiCode
Standard accessories	Barcode scanner, Data cable, Manual, Power adapter(optional for serial port)
