Handheld Portable 1D 2D Laser Barcode Scanner WiFi Wireless Data Collector Android Inventory Data Import/Export Stock

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	winson

Contact Now

Detailed Product Description

Private Mold:	Yes	Products Status:	Stock
Type:	Barcode Scanner	Scan Element Type:	CMOS
Colour Depth:	32 Bit	Interface Type:	Usb, PS/2
Max Paper Size:	N/a	Optical Resolution:	648 X 488 Pixel
Scan Speed:	350 ±50 Scans/second	Warranty(year):	1-Year
After-sales Service:	Call Center And On-line Technical Support	Software Development Kit (sdk):	NO
Color:	Black	Communication Mode:	Wired Transmission Mode
Communication Frequency:	2.400GHz - 2.483GHz ISM Band	Transmission Range:	50~80m(In Empty Area )
Battery Capacity:	2000mAh (Lithium Battery)	Charge Time From Empty To Full Charge:	4H
Continuous Working Hours:	8H	Memory:	The Flash Is 16M And Stores 2 Million Characters
Interface Supported:	RS232/USB HID KEYBOARD/USB VCP	Input Voltage:	DC 5V±5%
Current:	Max:220mA

Product Description

Specification

Communication mode	Wired transmission mode/ Wireless Read-time mode/Inventory mode／Cache mode
Communication frequency	2.400GHz - 2.483GHz ISM band
Transmission range	50~80m（In empty area ）
Battery capacity	2000mAh (Lithium battery)
Charge Time from Empty to Full Charge	4H
Continuous working hours	8H
Memory	The flash is 16M and stores 2 million characters
Interface Supported	RS232/USB HID KEYBOARD/USB VCP
Input Voltage	DC 5V±5%
Current	Max:220mA
Image Sensor	CMOS Array Sensor
Sensor Resolution	640 X 480 Pixels
Light Source	white LED
Aiming light source	RED LED
Decoding speed	60FPS
Scanning Angle	Pitch angle:±65°;Skew angle:±65°;Tilt angle:±360°
Field of View	36H),27V)
Min Resolution	≥20% UPC/EAN 13（13mil）
Language	Multiple Languages
Data Edition	Support for custom data output
Decode Capability	1D:EAN-13，EAN-8，UPC-A，UPC-E，ISSN，ISBN，CodaBar， Code 128，Code93，ITF-14，ITF-6，Interleaved 2 of 5， Industrial 2 of 5，Standard 2 of 5，Matrix 2 of 5，GS1 Databar(RSS)，Code 39，Code 11，MSI-Plessey， GS1-Composite2D:QR Code，Data Matrix，PDF417，Micro PDF417，Micro QR， Aztec，Maxi Code，HanXin code
Weight	scanner :160g Lampstand:1g
Indicator	Beeper, LED
Dimensions	scanner :95mm65mm160mm(LWH) Lampstand:14mm x7mm x 19mm(LWH)
Shock Drop Test	1.5m drop onto concrete surface
