Name: High-Performance Barcode Scanner Sensor Interface Supports Multiple Codes-in Stock
Brand: Guangzhou Winson Information Technology Co., Ltd.
Availability: InStock

Home Products 1D CCD Barcode Scanner

High-Performance Barcode Scanner Sensor Interface Supports Multiple Codes-in Stock

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	winson

Contact Now

Detailed Product Description

Private Mold:	Yes	Products Status:	Stock
Type:	Barcode Scanner	Scan Element Type:	CMOS
Colour Depth:	32 Bit	Interface Type:	Usb, PS/2
Max Paper Size:	N/a	Optical Resolution:	648*480 Pix
Scan Speed:	5mil	Warranty(year):	1-Year
After-sales Service:	Return And Replacement, Others, Repair, Free Spare Parts, Onsite Training And Inspection, Call Center And On-line Technical Support	Software Development Kit (sdk):	NO
Color:	Orange, Black	Communication Mode:	Wired Read-time Mode
Photo Sensor:	Photo Sensor	Voltage Requirement:	Voltage Requirement
Memory:	100,000@13Byte Barcode	Battery Capacity:	2000mAh (Lithium Battery)
Min.Resolution:	0.076/3mil (PCS 0.9)

Product Description

Specification

Interface Supported	USB HID KEYBOARD/USB VCP
Input Voltage	DC 5V±10%
Current	Max:120mA
Laser	650nm visible laser diode
Decoding rate:	100 scans/second± 20 scans/second
Scanning Angle	Pitch angle:±35°;Skew angle:±75°;Tilt angle:±40°
Min Resolution	0.127/5mil（PCS 0.9）
Min .PCS value	〉25%UPC/EAN 13（13mil）
Language	Multiple Languages
Data Edition	Support for custom data output
Decode Capability	EAN13，EAN8，UPC A，UPC E，CODABAR（NW-7），CODE 39，CODE 93，INTERLEAVED 2OF5，STANDARD 2OF5，MATRIX 2OF5，CODE 128，EAN/UCC 128，CODE 11，CHINESE POST
Dimensions	67mm97mm165mm(LWH)
Weight	178g
Indicator	Beeper, LED
Temperature	-20°-65°C / -4°- 149°F((operation) ) -30°- 70°C /-22°- 158°F(storage)
