Handheld CMOS 2D Usb Barcode Reader 1D 2D Barcode Scanner for Barcode Printer

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	winson

Contact Now

Detailed Product Description

Private Mold:	Yes	Products Status:	Stock
Type:	Barcode Scanner	Scan Element Type:	CMOS
Colour Depth:	32 Bit	Interface Type:	Usb, SCSI, IEEE 1394, COM, PS/2
Max Paper Size:	N/a	Optical Resolution:	648*480 Pix
Scan Speed:	5mil	Warranty(year):	1-Year
After-sales Service:	Onsite Training And Inspection, Call Center And On-line Technical Support	Software Development Kit (sdk):	NO
Color:	Black	Interface Supported:	USB HID KEYBOARD/USB VCP Or RS-232
Input Voltage:	DC 5V±10%	Current:	240mA
Image Sensor:	CMOS Array Sensor	Sensor Resolution:	648 X 488 Pixels
Light Source:	White LED	Aim Light Source:	Red LED

Product Description

Specification

Interface Supported	USB HID KEYBOARD/USB VCP or RS-232
Input Voltage	DC 5V±10%
Current	240mA
Image Sensor	CMOS Array Sensor
Sensor Resolution	648 X 488 Pixels
Light Source	White LED
Aim Light Source	Red LED
Scanning Angle	Pitch angle:±60°;Skew angle:±60°;Tilt angle:±180°
Field of View	46°(H),35°(V)
Min Resolution	1D≥4mil 2D≥10mil
Min .PCS value	〉15% UPC/EAN 13（13mil）
Language	Multiple Languages
Data Edition	Support for custom data output
Decode Capability	1D： Codabar，Code128，Code11，Code32，Code39，Code93，Composite，EAN/UPC,EAN-8,EAN-13,GS1 DataBar Expanded，GS1 DataBar Limited，GS1 DataBar Omnidirectional，Hong Kong 2 of 5（China Post），Interleaved 2 of 5，Matrix 2 of 5， Pharmacode.RSS-14,RSS-LIMITED,RSS-EXPANDED,Industrial 2 of 5,Telepen,Trioptic Code, UPC-A,UPC-E 2D：Aztec Code，Codablock F，DOT_CODE, HANXIN, Maxicode，MicroPDF417,Micro QR Code，MSI，PDF417,QR Code, DataMatrix
Dimensions	90mm67mm168mm(LWH)
Weight	120g
Indicator	Beeper, LED
